The bathroom water pipe is a very important part of the bathroom. It can be said that the water pipe is the soul element of the bathroom. Without the water pipe, the bathroom cannot perform its function normally. How to install the water pipes in the bathroom? Let’s take a look at the installation method of the water pipes in the bathroom with the editor.
Preparations before installation
1. There should be an indoor main valve for the water inlet. Before installation, it is necessary to check whether the water pipes and connecting accessories are damaged, sand holes, cracks, etc.
2. When installing kitchen and bathroom pipes, the size of the pipes outside the wall should take into account the final size after the wall tiles are pasted, that is, the thickness of the wall tiles should be considered in advance.
3. In the wall and under the ground, use less or no connecting accessories as much as possible to reduce the hidden danger of leakage. The installation of the connection fittings must be firm and free from leakage.
4. When designing water pipes, the installation position of the faucet of the washing machine and the layout of the water should be considered. At the same time, pay attention to whether the location of the power socket is appropriate. If you put a drum washing machine in the kitchen cabinet, you must determine the size of the washing machine and the kitchen cabinet, so as to reserve the position of the upper and lower water.
Bathroom plumbing installation method
1. The distance between the hot and cold water pipes in the bathroom must meet the decoration standards. The height of the shower pipe should be between 1.8M and 2.1M.
2. In the installation of water pipes in the bathroom, the cold and hot water outlets should be kept horizontal. Generally, the left side is hot and the right side is cool. The position of the pipe clamp and the slope of the pipe shall meet the requirements of the specification. All kinds of valves should be installed in the correct position and level, which is convenient for use and maintenance.
3. Both the cold and hot water pipes are built into the wall. When opening the groove, the depth of the groove must be checked, and the cold and hot water pipes cannot be in the same groove.
4. When installing the water heater inlet and outlet, the water inlet valve and the air inlet valve must be considered and installed in the corresponding positions.
Precautions for toilet plumbing installation
1. Design and layout of toilet water pipes
The bathroom water pipe installation should be laid according to the direction of the water. Generally, the two pipes should not intersect. And installed in the middle of the bathtub, the height is preferably between 1.8 meters and 2.1 meters. It is also necessary to reserve a place for the installation of the water heater and the water inlet and outlet of the washing machine, so as to achieve a scientific and reasonable layout.
Second, the correct sequence of toilet water pipe installation
Before installing the water pipes in the bathroom, you must follow certain reasonable steps. Generally, you must first discuss the specific direction of the waterway with the installer. The second step is to use an electric hammer to fix the clips to the wall. The third step is to start using a professional hot-melt machine Hot-melt connection of the pipes, the fourth step is to test the pressure of the entire pipeline with a pressure test pump, and the fifth step is to clean up the site.
3. Pressure measurement process of toilet water pipe
Before the pressure test, the valve behind the water meter should be closed, the end of the pressure test pipe should be blocked, and water should be injected slowly. After filling the water, check the seal, and then manually increase the pressure. After the pressure is stabilized, the pressure drop within half an hour does not exceed 0.05Mpa, which is qualified. .
This is the end of the introduction to the installation method of bathroom water pipes. Everyone should have a new understanding of the knowledge of bathroom water pipe installation. Don’t underestimate the installation of a water pipe. It is the correct installation of a water pipe. The bathroom in the home can be used normally for a long time. Therefore, the installation of bathroom plumbing is also very important.
